Model: QT6-15
Exciting force(KN): 60
Vibration frequency(HZ): 0-60
Power(KW): 34.28
Forming type: Fully automatic loading and molding
Forming cycle(S): 15-20
Outline dimension: 7160×2000×2800
Pallet size: 880×680×20
Normal output: 85000
1. Fully automatic block machine whole production line
2. QT6-15 block machine construction needed super parts
· Automatic control system
· PLC control system
· Hydraulic pressing system
· High quality, ISO9001 certification
· Perfect oil system
· Siemens electronic system
· Self-diagnose system
· Multiply-function forming system
· Frequency vibration system
· Germany technology
3. Application: Widely used in construction, roads, parks, greening, urban construction and so on
Model | Products | Size | Block Qty/Plate | PCS/Hour | PCS/8Hours |
QT6-15 | Hollow Blocks | 390×190×190 | 6 | 1440 | 11520 |
Perforated Blocks | 240×115×90 | 18 | 4320 | 34560 | |
Solid Blocks | 240×115×53 | 30 | 8640 | 69120 |
Model | QT6-15 |
Mixer | JS500 |
Batcher | PLD800 |
Cement Silo | sheet-assembled 50T |
Screw Conveyer | LSY 219*8m |
Power(KW) | 34.28 |
Forming type | Fully automatic loading and molding |
Control type | PLC Semi-automatic control PLC |
Forming cycle (S) | 15-20 |
Outline dimension | 7160×2000×2800 |
Weight (T) | 7 |
Pallet size | 880×680×20 |
