JZM Diesel Concrete Mixer

1. Excellent manufacturing team with experience of over 20 years.
2. All can be customized to meet your needs&boost productivity.
3. Passed CE&ISO9001:2008 quality attestation.
4. Long-term cooperated transport company ensure the timely and safe delivery.
5. One-stop service save your precious time.

JZM series Mobile Mixer Machine is a self-falling concrete mixing machine. It can mix plastic and semi-dry hard concrete.

It uses rubber roller friction drive. It has advantages such as low noise stable running operation easy to move good mixing quality higher production efficiency and can applies in the general construction site like roads bridges and water and electricity projects especially in urban residential construction.

Model		JZM350	JZM500	JZM750
Nature of work	Discharge capacity	350L	500L	750L
	Feeding capacity	560L	800L	1200L
	Productivity	13 m3/h	18-20m3/h	30-35m3/h
	Mixing drum rotating speed	15 r/min	15 r/min	12.26r/min
	Max.aggregate particle	60mm	60mm	80mm
	Precision of water supply	≤2%	≤2%	≤2%
motor	Agitator motor	5.5KW	2×5.5KW	2×7.5KW
	Lifting motor	4.5KW	5.5KW	7.5KW
	Pump motor	0.75KW	1.1KW	1.1KW
Tire specifications		650-16	700-16	750-16
Maximum towing speed		20km/h	20km/h	20km/h
Outline dimension (LWH)		380020502690	571023505050	621623006060
